The
5040 aluminum square bar is mainly used for high-quality plasticity and good weldability. Low-load parts working in liquid or gaseous media, such as mailboxes, gasoline or lubricating oil pipes, various liquid containers and other deep-drawing products. Small load parts: Wire is used to make rivets. It is also commonly used in transportation vehicles, ship sheet metal parts, instruments, street lamp brackets and rivets, hardware products, electrical enclosures, etc.
Chemical component
|
Element |
Si |
Cu |
Mg |
Zn |
Mn |
Cr |
Fe |
Al |
|
Standards |
0.25 |
0.1 |
2.2-2.8 |
0.1 |
0.1 |
0.15-0.35 |
0.4 |
Reminder |
Physical properties
Tensile Strength
(MPa) |
Yield Strength
(MPa) |
Modulus of Elasticity
(E) |
|
170-305 |
≥65 |
69.3-70.7Gpa |
The products supplied by Chalco are strictly produced according to various national standards such as GB/T3191-2010, GB/T6892-2006 and GB/T3190-2008 to ensure the excellent quality of the products. The product can be customized according to the special requirements of the customer.
